Prototype Design Pattern in .NET Core API

Intro

When I started building APIs that needed to produce slightly varied copies of complex objects, I quickly realized that calling new each time and copying each field by hand was tedious and error-prone. That is when the Prototype pattern made a lot of sense. Instead of rebuilding an object from scratch, you clone an existing one and only adjust what needs to change.

What Is the Prototype Pattern?

Prototype is a creational design pattern that lets you create new objects by copying an existing instance rather than constructing one from scratch. The existing instance acts as a template, or prototype, and cloning it produces a new independent object.

In plain terms, instead of calling new and setting up every property yourself, you ask an existing object to copy itself and then make only the small changes you need.

Prototype Class Example

The scenario below shows a document template system used in an API. Each template can be cloned to produce a new draft without touching the original.

public interface IDocumentPrototype
{
    IDocumentPrototype Clone();
}

public class ReportTemplate : IDocumentPrototype
{
    public string Title { get; set; } = string.Empty;
    public string Category { get; set; } = string.Empty;
    public List<string> Sections { get; set; } = new();

    public IDocumentPrototype Clone()
    {
        return new ReportTemplate
        {
            Title    = this.Title,
            Category = this.Category,
            Sections = new List<string>(this.Sections)
        };
    }

    public override string ToString() =>
        $"[{Category}] {Title} — Sections: {string.Join(", ", Sections)}";
}

Usage

var masterTemplate = new ReportTemplate
{
    Title    = "Monthly Summary",
    Category = "Finance",
    Sections = new List<string> { "Overview", "Revenue", "Expenses" }
};

var aprilDraft = (ReportTemplate)masterTemplate.Clone();
aprilDraft.Title = "April Monthly Summary";

Console.WriteLine(masterTemplate);
Console.WriteLine(aprilDraft);

Why This Works

Clone Method

Independent Copy

Flexible Customization

When to Use It

Prototype is a good fit when creating an object from scratch is expensive or complicated.

• copying a pre-configured request or response object with shared defaults
• generating draft documents from a master template
• duplicating complex entity graphs in domain-driven design
• seeding test data with slight variations from a known baseline

That said, if the object is cheap to create and has few fields, plain construction is simpler. Use Prototype when the object is complex enough that cloning saves real effort.

Important Note for ASP.NET Core

In ASP.NET Core, you can register a prototype factory so that each call to resolve the service produces a fresh clone of a pre-configured instance rather than building from nothing.

var master = new ReportTemplate
{
    Category = "Finance",
    Sections  = new List<string> { "Overview", "Revenue", "Expenses" }
};

builder.Services.AddTransient<ReportTemplate>(_ =>
    (ReportTemplate)master.Clone());

This approach ensures each request gets its own independent copy without repeating the shared setup, and the container still manages the lifetime cleanly.

Core Components of the Pattern

Common Prototype Variations

You will usually see Prototype implemented in a few common ways:

Shallow Copy

Uses MemberwiseClone() to copy value-type fields and reference addresses. Fast, but the clone shares reference-type members with the original.

Deep Copy

Manually copies every nested object so the clone is fully independent from the original. This is the version shown in the example above.

Prototype Registry

A central store of named prototypes. Clients request a clone by key, and the registry returns a fresh copy of the registered prototype without exposing any concrete type.

How the Variations Differ

SOLID Principles Behind It

SRP — Single Responsibility Principle

Each concrete prototype is responsible for knowing how to copy itself. The client does not need to know the internals of construction.

OCP — Open/Closed Principle

You can introduce new prototype types without changing existing client code. Clients call Clone through the shared interface.

LSP — Liskov Substitution Principle

Any concrete prototype can replace another wherever the interface is expected, because each Clone call returns a valid, independent copy.

DIP — Dependency Inversion Principle

The client depends on the IDocumentPrototype abstraction. It never references a concrete class directly.

UML Diagram

classDiagram
    class Client
    class Prototype {
        +Clone()
    }
    class ConcretePrototype
    class Registry

    ConcretePrototype --|> Prototype
    Registry --> Prototype
    Client --> Prototype
    Client --> Registry

A Quick Usage Example

var first  = (ReportTemplate)masterTemplate.Clone();
var second = (ReportTemplate)masterTemplate.Clone();

first.Title  = "Q1 Report";
second.Title = "Q2 Report";

Both variables are independent copies of the same master template. Changing one does not affect the other or the original.

How to Validate the Pattern

If you want to confirm that your Prototype is working correctly, check these points:

• cloned objects should be equal in value but not the same reference
• changes to the clone should not affect the original
• nested reference-type fields should also be independent in a deep copy
• a prototype registry should return a fresh clone on every call, not the stored prototype itself

A simple practical check is to clone an object, modify a field on the clone, and then print both. If the original remains unchanged and the references differ, the pattern is behaving as expected.

Is there any other way to check our implementations

• Yes, we can write test cases for those implementations
• Here is the link, to test using unit test cases

Summary

The Prototype pattern avoids the cost and complexity of rebuilding objects from scratch by cloning a pre-configured instance. It decouples the client from concrete constructors, keeps shared setup in one place, and makes it straightforward to produce independent variations of a complex object.
