Command Design patterns

Intro

The Command pattern allows you to represent operations as standalone objects. This gives your system flexibility, lets you manage requests in a uniform way, and enables powerful features like undo/redo, logging, and task scheduling—all while keeping the requesting code and the executing code independent of each other.

Core components in Command Design Pattern

Which Solid Priciple implemented in this Pattern?

Real-World Analogy

• A customer comes to hotel and try to give an order
• The waiter (invoker) takes your order ( command object) and pass to kitchen (receiver)
• The waiter doesn’t know about how the chief cooks
• The order can be queued, modified, cancelled or repeated with outchanges the waiter process

UML Diagram

Simple Command Pattern

Purpose

This solution implements a command-based banking system where financial transactions (deposits and withdrawals) on an account can be executed, tracked, and reversed in a reliable and structured manner. The design uses the Command Pattern to encapsulate transaction logic, enabling features like undo/redo, transaction grouping, and auditability.

GitHub Repository

Core Business Rules and Logic

1. Account Management

• Object: Account

• Responsibilities:

  • Maintains the account balance and applies an overdraft limit for withdrawals.
  • Provides methods for depositing funds (increasing balance) and withdrawing funds (reducing balance), with validation against the overdraft policy.
  • Exposes current balance for display or auditing purposes.

• Business Rule Details:

  • Any deposit directly increases the balance. Deposit:
  • A withdrawal only succeeds if the resulting balance does not violate the overdraft limit. Withdraw:
  • Balance Visibility: The current balance is accessible (read-only) at any time for reporting.

2. Transaction Encapsulation (Command Pattern)

• Components: , ICommand``BankAccountCommand

• Responsibilities:

  • Encapsulates each banking operation (deposit or withdrawal) in a separate command object.
    • Each command knows how to execute its operation and how to undo it—enabling features like transaction reversal.
    • Records the execution state of each command for reliable undo/redo operations.

• Business Rule Details:

  • Command Creation: Each operation (either deposit or withdraw) is wrapped within a command that stores the type of action, the target account, and the transaction amount.
    • Execution: Calling on a command performs the transaction on the account. Execute
    • Undo: Calling on the command reverses the performed action (withdraw undoes a deposit and vice versa), only if the command was executed successfully. Undo

3. Batch Processing and Transaction History

• Component: Main program logic () Program.cs

• Responsibilities:

  • Creates a series of commands representing a batch of transactions.
    • Executes all transactions sequentially.
    • Allows transactions to be reversed (undone) in reverse order, preserving the integrity of the account’s state.

• Business Rule Details:

  • Batch Execution: All commands in a list are executed on a single account, updating the balance step by step.
    • Undo Mechanism: By reversing through the command history and calling , all transactions can be rolled back to their original state, supporting audit trails and error correction. Undo

Code Explaination

Command Interface

• Component: interface (in ICommand.cs) ICommand
• Role: Declares the contract for command objects ( and methods). Execute``Undo

      public interface ICommand
      {
          void Execute();
          void Undo();
      }

Concrete Command

• Component: class (in ICommand.cs) BankAccountCommand
• Role: Implements the interface, encapsulating a request to perform deposit or withdrawal on an account. ICommand

    public class BankAccountCommand : ICommand
{
    private readonly Account _account;
    private readonly ActionType _actionType;
    private readonly int _amount;
    private bool _isExecuted;

    public enum ActionType
    {
        Deposit,
        Withdraw
    }

    public BankAccountCommand(Account account,
        ActionType actionType,
        int amount)
    {
        _account = account;
        _actionType = actionType;
        _amount = amount;
    }
    public void Execute()
    {
        switch (_actionType)
        {
            case ActionType.Deposit:
                _account.Deposit(_amount);
                _isExecuted=true;
                break;

            case ActionType.Withdraw:
                _isExecuted=_account.Withdraw(_amount);
                break;

            default:
                break;
        }
    }

    public void Undo()
    {
        if (!_isExecuted) return;
        switch (_actionType)
        {
            case ActionType.Deposit:
                _isExecuted= _account.Withdraw(_amount);
                break;
            case ActionType.Withdraw:
                _account.Deposit(_amount);
                _isExecuted=true;
                break;
            default:
                break;
        }
    }
}

Receiver

• Component: class (in Account.cs) Account
• Role: Performs the actual business logic: deposit and withdraw money. The command delegates the actual work to this receiver.

 public class Account
{
    private int _balance;
    private readonly int _overdDraftLimit;

    public void Deposit(int amount)
    {
        _balance += amount;
        WriteLine($"Deposit amount ${amount}  ");
        WriteLine($"Balance is ${_balance}");
    }

    public bool Withdraw(int amount)
    {
        if (_balance - _overdDraftLimit < amount) return false;
        _balance -= amount;
        WriteLine($"Withdraw amount ${amount}");
        WriteLine($"Balance is ${_balance}");
        return true;
    }

    public int GetBalance => _balance;
}

Invoker

• Component: The code in Program class that loops through the list of commands and invokes and (in Program.cs) Execute()``Undo()
• Role: Initiates execution or reversal of commands without knowing their details.

  foreach (var cmd in command)
        {
            cmd.Execute();
        }

Client

• Component: The code in Main method that creates the , instantiates the objects, and prepares the list of commands (in Program.cs) Account``BankAccountCommand
• Role: Sets up everything: creates the commands, sets up the receiver (account), and hands over the commands to the invoker logic.

internal static class Program
{
    private static void Main(string[] args)
    {
        var account = new Account();
        var command = new List<BankAccountCommand>
        {
            new BankAccountCommand(account, BankAccountCommand.ActionType.Deposit, 100),
            new BankAccountCommand(account, BankAccountCommand.ActionType.Withdraw, 500),
        };
        WriteLine(account.GetBalance);

        foreach (var cmd in command)
        {
            cmd.Execute();
        }
        WriteLine(account.GetBalance);

        WriteLine("Reverse order");
        foreach (var cmd in Enumerable.Reverse(command))
        {
            cmd.Undo();
        }
        WriteLine(account.GetBalance);
    }
}
